HD130A Bulldozer
HD130A Bulldozer
14500 (XL) / 15300 (LGP) kg
117 kW
Technical details
Product Overview
The new Hyundai HD130A XL has a narrow width, while the HD130A LGP provides lower ground pressure. Both dozers deliver best-in-class horsepower and weight for better traction to push more material, while Smart Technologies and unbeatable visibility help operators of all skill levels achieve greater grading precision. A highly durable undercarriage stands up to the toughest conditions to get more work done, while lowering maintenance costs.
Reasons to choose the HD130A Dozer
Trust Hyundai for Productivity
With best-in-class horsepower and machine weight, you get more power to the ground and superior tractive effort. This helps you push more material and maximise productivity.
- Max forward and reverse speeds allows for quick and easy movement around the jobsite.
- A 132L/min hydraulic pump delivers up to 22,000kgf of traction force.
- A two-speed transmission enables a maximum travel speed of 9.0km/h with a 35° (70%) gradability.
- A 3.54m3 XL blade is standard, while a 4.18m3 capacity LGP blade is available as an option.
- Ripper attachment as standard features parallel linkage that helps maintain a constant angle to the ground regardless of the height.
Trust Hyundai for Efficiency
Designed for efficiency, the HD130A features an Eco Mode that reduces hydraulic pump power output for lighter grading tasks, cutting fuel consumption by up to 5%. Smart fuel-saving technologies like Auto Idle and Auto Shutdown prevent unnecessary idling, optimising fuel use throughout the workday.
- Eco Mode, Auto Idle, and Auto Shutdown reduce fuel consumption and operating costs.
- Tilt and angle adjustment makes it easier to work more efficiently, reducing the number of passes required to achieve grade.
- Powered by a highly-efficient Perkins 4.4-litre diesel engine.
- A standard 2D Blade Dozing Assist Function helps less experienced operators achieve precise grading results without requiring lasers or GPS control.
Trust Hyundai for Safety & Comfort
The HD130A is designed to provide operators with a comfortable, intuitive, and highly efficient working environment. Full-height glazed doors on both sides, along with a hidden engine air pre-cleaner, maximise visibility to the blade. A range of advanced features, including a rear-view camera, LED work lights, and an intuitive touchscreen display, ensure ease of operation.
- Spacious ROPS/FOPS cab with CabSus mount, full-height glazed doors, and an optimised engine canopy.
- A 2-way proportional auxiliary joystick, fully electrohydraulic controls and pedal control enable effortless operation.
- Rear-view camera, touchscreen display, Bluetooth audio system, and safety features like an automatic shut-off and seatbelt alarm.
- GPS-based remote monitoring for real-time performance tracking, maintenance alerts, and dealer support.
- Tapered, slim engine canopy that maximises visibility to the blade tips.
Trust Hyundai for Serviceability
The Hyundai HD130A is designed for easy maintenance and long-term reliability, ensuring maximum uptime on the job site. Daily service points are conveniently accessible from ground level, while wide-opening access doors provide clear entry to key components.
- Ground-level service points and wide-opening access doors for hassle-free inspections.
- Rear-tilting cab structure allows direct entry to major hydraulic and drivetrain components.
- Heavy-duty design with single and double-flanged rollers to maximise longevity.
- Optional Hi-MATE remote management system helps provide the highest level of service and product support available.
FAQs about the HD130A Dozer
Does the HD130A comply with the European stage V emission levels?
Yes. Its high performance engine delivers better productivity and fuel efficiency while meeting EU Stage V emissions regulations
Does the HD130A integrate with Hi Mate?
Yes. Hyundai’s innovative Hi MATE telematics system enables full monitoring of machine activity and performance.
What is the operating weight of the HD130A bull dozer?
The operating weight is 14500 (XL) and 15300kg (LGP).
What industry and application is the HD130A bull dozer used in?
The HD130A bull dozer is designed for pushing large amounts of materials during construction work.
